type | item | Technical Specifications |
electrical control | VFD | Taida(China) |
relay | CHNT(China) |
buttons | CHNT(China) |
contactor (switch) | CHNT(China) |
tranformer | CHNT(China) |
phase sequence | CHNT(China) |
joystick | CHNT(China) |
materials of construction | fixed end | 6mm(material:SPCC) |
first Expansion | 5mm(material:SPCC) |
second Expansion | 5mm(material:SPCC) |
third Expansion | 4mm(material:SPCC) |
belt driven roller | Φ219mm，thickness≥6mm,(Seamless Steel Tube) |
Rubber covering of belt driven roller | ≥10mm |
driving roller middle shaft | Φ45mm(material:C45) |
belt driven slave roller | Φ89mm，thickness≥5mm,(Seamless Steel Tube) |
driving slave roller middle shaft | Φ45mm(material:C45) |
support roller | Φ50mm |
belt | material | PVK |
brand | Forbo or Yongli |
width | 800mm |
thickness | 3mm |
grade | industry |
